CPAN dependency confusion

Rationale

Take advantage of an incorrectly configured setup that resolves a public module (published on CPAN) in place of the expected private/local version due to one of the following reasons:

  • Local module is not installed at the time of running the CPAN client
  • Public CPAN version is preferred to local
  • Using a CPAN repository (proxy) that can be confused

This type of vulnerability was proved to affect other ecosystems (PyPI, RubyGems and NPM). This is presented in Dependency Confusion by Alex Birsan.

Background

“Dependency confusion” takes advantage of mixing (semi-)private modules with public CPAN modules.

In the Perl ecosystem, it could be one or more of the following options:

  • Using a “DarkPAN” along with CPAN
  • Using a “GrayPAN” along with CPAN
  • Using a “BackPAN” along with CPAN
  • Mixing manual installs (make install, “blib install”…) along with CPAN

See About the various PANs for details about DarkPAN and GrayPAN.

An attacker can “claim” a public namespace, install a high version (to take precedence in the index over a smaller local version number) and wait for vulnerable setups to install (and execute) their newly uploaded module.

Not all uploads end into claiming a namespace or a new version of a module (both can be referred as “indexing”). Permissions on name (FIRSTCOME, COMAINT…) and status of release (development version) impacts the visibility of releases. Index and visual appearance in MetaCPAN would make it clear, highlight dev or “unauthorized” releases and finally, not installable.

See PAUSE operating model for details.

General about CPAN dependency management

The mirror versus the indexer

The notions of “mirror” and “indexer”:

  • “mirror” - where module tarballs are stored
  • “indexer” - translate module to path and version

These notions are not always well differenciated and their meaning heavily depends on the CPAN client. For instance, from a pool (urllist), CPAN.pm will use only one mirror for both indexing and downloading modules. On the other hand, cpanm will use MetaDB as the index in priority and the mirrors to download, and these notions are well decoupled.

Not all indexers are equals: 02packages only contains the latest version of each module, making it difficult to specify more complex constraints (pinned or ranges).

General characteristics about CPAN/PAUSE and installers

  • Module installs are (often) “dynamic” (= some dependencies are only known at install)
  • Claiming a namespace is case insensitive but index/install is case sensitive. It’s important for TypoSquatting or attacks based on modules/filenames collisions (e.g. GetOpt::Long would overwrite Getopt::Long module on a Windows machine).

Installer are not zealous

“leafs” vs “requirements”

CPAN installers treats differently a “leaf” versus a “requirement”.

Specifying a module as a “leaf”, e.g. cpanm Requirement is different from having it specified as a dependency (Makefile.PL/Build.PL, META.*, cpanfile…)

  • When explicitly targeting to install Requirement, cpanm (and others) will install the latest, upgrading the module if present
  • When Requirement module is specified as a dependency, cpanm will not upgrade the module if the installed version satisfies the constraints

Installing with cpanm --installdeps . will not install anything:

  1. Requirement@0.01
  2. cpanm –installdeps .
  3. Requirement@0.01

But cpanm Requirement will update Requirement:

  1. Requirement@0.01
  2. cpanm Requirement
  3. Requirement@0.02

Note: This is not specific to the CPAN ecosystem, for instance pip and gem behave the same way.

--skip-satisfied

But cpanm --skip-satisfied Requirement will not update Requirement:

  1. Requirement@0.01
  2. cpanm –skip-satisfied Requirement
  3. Requirement@0.01

Simulations

Setup

For these tests, I’m recreating a setup with a mix of private and public modules.

As a commodity, it is presented as a cpanfile:

requires 'PrivateAndPublicGreaterCPAN', '0';
requires 'Private', '0';
requires 'Public', '0';
requires 'PrivateAndPublicGreaterLocal', '0';

It simulates a complex setup where the installer has to install some modules, sometimes local requirements and sometimes remote ones.

Specifying the requirements in Makefile.PL, Build.PL or META.json/META.yml achieves the same and was used in some cases (e.g. CPAN/CPANPLUS)

On DarkPAN:

PrivateAndPublicGreaterCPAN@0.03
Private@0.01
PrivateAndPublicGreaterLocal@0.02

On CPAN:

PrivateAndPublicGreaterCPAN@0.04
Public@0.12
PrivateAndPublicGreaterLocal@0.01

Private is only present on DarkPAN, Public is only present on CPAN.

PrivateAndPublicGreaterCPAN and PrivateAndPublicGreaterLocal are requirements that can be “confused” (if install ends up with PrivateAndPublicGreaterCPAN@0.04 and/or PrivateAndPublicGreaterLocal@0.02)

GrayPAN/DarkPAN was simulated with the following tools:

  • pinto either targetted via HTTP http://0.0.0.0:8000/ or file:///data/darkpan for cpanm, cpm, carton, carmel and cpan
  • CPAN::Mini for cpanplus (cpanplus index fetch incompatible with pinto)
  • StratoPAN/JFrog Artifactory for CPAN artifact manager proxy

Dependency confusion when local is non-existent

Unsafe

  • Specifying the private requirements in Makefile.PL, Build.PL, META.* or cpanfile/cpmfile is unsafe. Doing manual installs (via EUMM/MB or cpanm tarball) and then relying on requirements being already satisfied (and CPAN client not being “zealous”) to not install anything public is risky, to say the least.

Safe

  • Do not specify private requirements in Makefile.PL, Build.PL, META.* or cpanfile/cpmfile. Specifying requirements is technically not required for runtime. This is suboptimal because it makes dependencies implicit and shifts right the verification of requirements.
  • Use reserved namespaces (_Underscore::Trick) that can not resolve to public modules.

Documented but unsafe

Local::* is documented as a name space for private modules but as of November 2024 only reserved “by convention”, see Do not index Local::* (nor Local)

Dependency version confusion between PANs

Unsafe

cpanm –mirror

  • It keeps resolving first via public indexer (has no information about DarkPAN versions)
  • It only “appends” so beware mirrors installed first via PERL_CPANM_OPT
  • Order is important

e.g.:

  • Problem with “appends”: PERL_CPANM_OPT="--mirror https://cpan.org" cpanm --mirror-only --mirror http://darkpan.local --installdeps .
  • Problem with “indexer”: cpanm --mirror http://darkpan.local --mirror https://cpan.org --installdeps .
  • Problem with “ordering”: cpanm --mirror-only --mirror https://cpan.org --mirror http://darkpan.local --installdeps .

cpanfile/cpanm

  • mirror "" and mirror => directives from cpanfile are (silently) ignored by cpanm (!)
# WRONG with cpanm

mirror "https://darkpan.local/";

requires 'PublicAndPrivateGreaterCPAN', '0',
  mirror => 'https://darkpan.local/',
  dist => 'USER/PublicAndPrivateGreaterCPAN-0.03.tar.gz';

cpanfile/carton

  • per req mirror => alone (without dist =>) is silently ignored by carton
  • per file mirror "" is not used for index by carton
  • PERL_CARTON_MIRROR="https://pause.local/" carton install - error prone (mirror is not explicited in requirements file)

cpanfile/carmel

Safe

  • cpanm --from - but requires full sync DarkPAN or to differenciate private and public cpanfile(s)
  • unset PERL_CPANM_OPT cpanm --mirror-only --mirror darkpan --mirror cpan - beware order of mirrors
  • unset PERL_CPANM_OPT cpanm --mirror-index file:///data/02packages --mirror darkpan --mirror cpan - beware order of mirrors
  • unset PERL_CPANM_OPT cpanm --cascade-search --mirror-index file:///data/02packages --mirror darkpan --mirror cpan - beware order of mirrors
  • cpm --no-default-resolvers --resolver darkpan --resolver cpan
  • carton/cpanfile mirror => AND dist => - pinned version and storage
  • carton/cpanfile url => - pinned url
  • CPAN urllist (but with pushy_https disabled) - use index of first mirror, fallback for download
  • CPANPLUS hosts - use index of first mirror, fallback for download

Carton pinning with url =>:

requires 'Private', '0',
  url => 'https://darkpan.local/authors/id/U/US/USER/Private-0.01.tar.gz';

Deployment and lockfiles

Lockfiles mostly refers to the deployment phase that is out of scope of this document.

carton --deployment and carton --cached are not vulnerable, because they use dumped/recreated local index with local artefacts.

CPAN Artifacts Repositories

JFrog Artifactory

JFrog is known to be vulnerable (internally) to these dependency confusion attacks with other ecosystems.

Since JFrog Artifactory does not support CPAN as a first class citizen but only a “proxy” CPAN (as in “HTTP proxy”), CPAN is not vulnerable via this artifact repository manager.

StratoPAN

Not affected, not doing fallback on the public CPAN.

Mitigations

Beyond technical CPAN client/options recommendations exposed earlier, sharing some more “shift left” guards and explicit security advice.

PAUSE operational model

The way CPAN and PAUSE work, and the very “social” nature of this ecosystem makes it very difficult to attack CPAN via dependency confusions.

  1. New authors don’t immediately get an account but are approved by an admin. With a priori approval like this, automatic creation of fake accounts is less likely.
  2. New uploads do not follow a priori control but are publicly reviewed. Malware code can be spotted and claiming namespaces with bad intention would likely be reported rapidly.

In this context, it seems difficult for an attacker/malware module to go unnoticed and exploit dependency confusion.

But still, PAUSE and CPAN have experienced some “raids” of spam, see for instance the surge in spammy accounts (and uploads) in August 2018.

Isolate private requirements

  • Use different files for private and public requirements (cpanfile.private / cpanfile)
  • Do not specify private requirements in Makefile.PL, Build.PL, META.* or cpanfile/cpmfile

Both previous solutions are sub-optimal

Naming

Scoping like NPM

Remediation for NPM ecosystem mentions scoping (naming packages like @my-company/my-module). A scope guarantees protection of all names under it but also can be tied to a registry.

The CPAN operating model works differently and has no such scopes. Technically, being the first person to publish a module offers FIRSTCOME permissions on the module name. Though it does not recusively protect all names under it, it effectively protects the fully qualified name forever.

Doing this (“placeholding”) for private modules is an option, but it would be very unwise and very egoist to do that, effectively polluting the CPAN namespace for personal needs. Beyond these considerations, you need only publish once (a very small version that never will interfer with your local versioning) to claim the namespace. Remember, it’s not a scope. Claiming Module does not protect Module::Foo nor Module::Bar.

The module install somewhat fills this use case, like gem bundle in rubygems.

Reserved namespaces

Use reserved namespaces that can’t resolve to public things:

From PAUSE Naming Modules - Local:: and The Perl Module Library (perlmodlib)
